Imagine a world without WiFi. We would still be using long wires of ethernet cables to connect to the internet.
There is no debate on how much WiFi has made our lives easier. Now we can connect to the internet in coffee shops, subway stations, and almost anywhere we go.
However, WiFi is also a vulnerable network compared to the ethernet. Unless it is properly secured, it's easy to perform man-in-the-middle attacks using tools like Wireshark.
For example, if you are connected to a Starbucks network, anyone connected to that network can look at every other person’s network traffic. Unless you use a VPN or the website uses https, your data (including passwords and credit card details) will be visible to the entire network.
If you are working for a company, chances are, they use WiFi networks too. Have you wondered how secure it is? Do you know if someone in the parking lot is connected to your network and capturing your company’s confidential data?
With tools like Wireshark and Aircrack, you can perform security audits of your WiFi networks. While Wireshark can help you watch what is happening on your network, Aircrack is more of an offensive tool that lets you attack and gain access to WiFi networks.
A quick sidenote: I am in no way encouraging the use of illegal offensive tools. These are purely educational and to help you defend your networks better.
Before we look at Aircrack in detail, here are a few terms you should know.
- Access Point — The WiFi network that you want to connect to.
- SSID — The name of the access point. e.g. “Starbucks”
- Pcap file — Packet capture file. Contains captured packets on a network. The common format for tools includes Wireshark and Nessus.
- Wired Equivalent Privacy (WEP) — Security algorithm for wireless networks.
- Wi-Fi Protected Access (WPA & WPA2) — Stronger security algorithm compared to WEP.
- IEEE 802.11 — Wireless Local Area Network (LAN) protocol.
- Monitor mode — Capturing the network packets in the air without connecting to a router or access point.
I recently wrote a post on the top 100 terms you should know as a penetration tester. You can check it out if you are interested.
Aircrack is a software suite that helps you to attack and defend wireless networks. Aircrack is not a single tool, but a suite of tools, each of which performs a specific function. These tools include a detector, packet sniffer, WEP/WPA cracker, etc.
The main purpose of Aircrack is to capture the packets and read the hashes out of them in order to crack the passwords. Aircrack supports almost all the latest wireless interfaces.
Aircrack is open-source and can work on Linux, FreeBSD, macOS, OpenBSD, and Windows platforms.
The ‘NG’ in Aircrack-ng stands for “new generation”. Aircrack-ng is an updated version of an older tool called Aircrack. Aircrack also comes pre-installed in Kali Linux.
Before we start working with Aircrack, you will need a WiFi adapter. Aircrack only works with a wireless network interface controller whose driver supports raw monitoring mode and can sniff 802.11a, 802.11b, and 802.11g traffic.
Typical WiFi adapters (usually built-in with your computer) don't have the ability to monitor traffic from other networks. You can only use them to connect to a WiFi access point.
With an Aircrack compatible WiFi adapter, you can enable the ‘monitor mode’ with which you can sniff traffic from networks you are not connected to. You can then use that captured data to crack the password of that network.
Now that you know what you can do with Aircrack, let’s look at each of its tools.
Airmon-ng is a script to place your network interface card into monitor mode. Once this is enabled, you should be able to capture network packets without the need to connect or authenticate with an access point.
You can use the command ‘airmon-ng’ to list the network interfaces and ‘airmon-ng start <interface name>’ to start an interface in monitor mode.
# airmon-ng start wlan0 PID Name 718 NetworkManager 870 dhclient 1104 avahi-daemon 1105 avahi-daemon 1115 wpa_supplicant PHY Interface Driver Chipset phy0 wlan0 ath9k_htc Atheros Communications, Inc. AR9271 802.11n (mac80211 monitor mode vif enabled for [phy0]wlan0 on [phy0]wlan0mon) (mac80211 station mode vif disabled for [phy0]wlan0)
In the above example, you can see that the network interface “wlan0” has been turned into “wlan0mon” — meaning the monitor mode has been enabled for it.
Airodump-ng is a packet capture utility that captures and saves raw data packets for further analysis. If you have a GPS receiver connected to your computer, airodump-ng can fetch the coordinates of the access points as well.
After enabling monitor mode using airmon-ng, you can start capturing packets using airodump. Running the command ‘airodump-ng’ will list the available access points. The ESSID (or SSID) is the name of the wireless network.
# airodump-ng CH 9 ][ Elapsed: 1 min ][ 2007-04-26 17:41 ][ WPA handshake: 00:14:6C:7E:40:80 BSSID PWR RXQ Beacons #Data, #/s CH MB ENC CIPHER AUTH ESSID 00:09:5B:1C:AA:1D 11 16 10 0 0 11 54. OPN NETGEAR 00:14:6C:7A:41:81 34 100 57 14 1 9 11e WEP WEP bigbear 00:14:6C:7E:40:80 32 100 752 73 2 9 54 WPA TKIP PSK teddy BSSID STATION PWR Rate Lost Packets Notes Probes 00:14:6C:7A:41:81 00:0F:B5:32:31:31 51 36-24 2 14 (not associated) 00:14:A4:3F:8D:13 19 0-0 0 4 mossy 00:14:6C:7A:41:81 00:0C:41:52:D1:D1 -1 36-36 0 5 00:14:6C:7E:40:80 00:0F:B5:FD:FB:C2 35 54-54 0 99 teddy
Once you have captured enough packets using airodump-ng, you can crack the key using aircrack-ng. Aircrack uses statistical, brute force, and dictionary attacks to break the WEP / WPA key.
Aircrack-ng 1.4 [00:00:03] 230 keys tested (73.41 k/s) KEY FOUND! [ biscotte ] Master Key : CD D7 9A 5A CF B0 70 C7 E9 D1 02 3B 87 02 85 D6 39 E4 30 B3 2F 31 AA 37 AC 82 5A 55 B5 55 24 EE Transcient Key : 33 55 0B FC 4F 24 84 F4 9A 38 B3 D0 89 83 D2 49 73 F9 DE 89 67 A6 6D 2B 8E 46 2C 07 47 6A CE 08 AD FB 65 D6 13 A9 9F 2C 65 E4 A6 08 F2 5A 67 97 D9 6F 76 5B 8C D3 DF 13 2F BC DA 6A 6E D9 62 CD EAPOL HMAC : 52 27 B8 3F 73 7C 45 A0 05 97 69 5C 30 78 60 BD
It is important to note that you need enough packets in order to crack the key. Also, aircrack-ng uses sophisticated algorithms to crack the keys from the network packets. If you are interested in learning more about how Aircrack does this, this would be a good starting point.
Aireplay-ng is used to create artificial traffic on a wireless network. Aireplay can either capture traffic from a live network or use the packets from an existing Pcap file to inject it into a network.
With aireplay-ng, you can perform attacks such as fake authentication, packet injection, caffe-latte attack, etc.
The Cafe Latte attack allows you to obtain a WEP key from a client device. This is done by capturing an ARP packet from the client, manipulating it, and then sending it back to the client.
The client will then generate a packet that can be captured by airodump-ng. Finally, aircrack-ng can be used to crack the WEP key form that modified packet.
Airbase-ng is used to convert an attacker’s computer into a rogue access point for others to connect to. Using Airbase, you can pretend to be a legitimate access point and perform man-in-the-middle attacks on devices that connect to your system.
This attack is also called the “Evil Twin Attack”. Assuming you are in Starbucks trying to connect to their Wifi, an attacker can create another access point with the same name (usually with better signal strength) making you think that the access point belongs to Starbucks.
It is hard for regular users to differentiate between a legitimate access point and a rogue access point. So the evil twin attack remains one of the dangerous wireless attacks we encounter today.
In addition to these, there are a few more tools for you to use in the Aircrack arsenal.
- Packetforge-ng — Used to create encrypted packets for injection.
- Airdecap-ng — Decrypts WEP/WPA encrypted capture files after you crack the key with aircrack-ng. This will give you access to usernames, passwords, and other sensitive data.
- Airolib-ng — Stores pre-computed WPA/WPA2 passphrases in a database. Used with aircrack-ng while cracking passwords.
- Airtun-ng — Creates virtual tunnel interfaces.
The world is a more connected place, thanks to WiFi. We enjoy the benefits of WiFi almost every single day. With all its benefits, it is also a vulnerable network capable of exposing our private information, if we are not careful.
Hope this article helped you understand WiFi security and Aircrack in detail. To learn more about Aircrack in detail, check out their official wiki.
